309C-024-150/SL0

309C-024-150/SL0
Rotary actuator without spring return
24 VAC/DC, continuous (0)2…10 V
Torque 150 N
Run time 40 mm/min
Connection with
Feedback signal: (0)2…10 V
Shaft coupling: Spindle receptacle
Mounting with mounting rail + screws

Running time spring - without spring return
Position switch contact - without switch
Feedback - (0)2…10 V
Direction of rotation - selectable by switch
Manual operation - Push button
Force - 150 N
